The dolly the trucking industry copied.
Designed, engineered, and manufactured in Portland, Oregon. Pulling for the country's largest fleets and the U.S. military, decade after decade.
Up to 16%
Longer tire life, tested
No-slack
Suspension
11-stage
E-coat finish
A short history
The Eagle is not a new idea. It is the apex of an old one.
Silver Eagle has been building truck equipment in Portland, Oregon since 1933 — and converter dollies since 1955. Decades of refinement — better suspensions, better fifth wheels, better steel — have all flowed into the same product line. The Eagle is the modern version of the dolly that started it.
UPS, the U.S. Army, Frito-Lay, and Sysco have all pulled it — for many of them, as the prime specification. Every Eagle is welded, painted, and assembled on the same Portland factory floor where the original was built.
Why it pulls better
Three engineering decisions that show up in your fleet's P&L.
SUSPENSION
We pulled the load off the platform.
The Eagle's two-stage transverse leaf spring sits directly over the axle, not on a platform mount. Load travels straight through the spindle. The result is less wheel hop, less sway, and a quieter ride loaded or empty.
FIFTH WHEEL
Hook from the side. Every single time.
A front pull handle, a visual kingpin indicator, and a jaw that opens with half the exertion of a conventional fifth wheel. Cleaner hookups mean fewer high-pinning incidents — the mistake that injures drivers and idles equipment.
FRAME
Bolts, not welds. ¼-inch steel.
A bolt-together frame means a damaged crossmember gets replaced in the field — not cut out with a torch. Eleven stages of E-coat priming under a polyurethane topcoat seal the steel inside and out — including the cavities a spray gun never reaches.
Portland, Oregon · Since 1933
One family. One factory floor. Since 1933.
Silver Eagle has built truck equipment in Portland, Oregon since 1933 — and converter dollies continuously since 1955. Same shop floor. Same engineering discipline. The Eagle you order today is welded, E-coated, and assembled by the same team that builds the dollies for the U.S. Army and the country's largest parcel fleets.
The coupling principle under every Eagle traces to the company's own 1938 fifth-wheel patent — drawn, refined, and still built in the same city.
90+
Years in business
70K
Sq ft shop floor
100%
In-house production
Trusted by
The country's largest parcel fleet, the U.S. Army, and a long list of food and beverage operators have pulled Silver Eagle dollies for decades.
Engineering data
Technical specifications.
- WEIGHT
- 2,900 Ibs (1,315 kg)
- GVWR
- 20,000 Ibs (9,071 kg)
- Frame and Drawbar
- Formed steel channel drawbar and frame 78″ center of drawbar eye to center of axle Drawbar eye is rubber mounted in steel shock housing. Drawbar set for 34″ hitch height
- Fifth Wheel
- 36″ fabricated steel table with cast steel center section Roadside release handle Fifth wheel mounted directly over centerline of axle
- Axle
- Meritor TN 4671, 5″ round with N-spindles 22,500 Ibs installed to set toe-in at 1/16″/71 ½” track for 96″ or 102" wide trailers
- Hub / Drum
- Cast hubs for dual 10 stud Two hand hole steel disc wheels Outboard mount cast iron brake drums brake drums
- Brakes
- Meritor 16W’ x 7″ Q+ S-cam brakes with non-asbestos linings ABS Type 30 service chambers with stroke indicators Automatic slack adjusters
- Suspension
- 7-leaf, two stage springs with rebound leaves Transverse-mounted over axle Spring eyes are secured in rubber mounting blocks
- PAINT
- Steel shot blasted frame and fifth wheel, treated with an 11-stage epoxy primer (E-coat) Top coat is high-quality gray polyurethane
- AIR SYSTEM
- ABS relay, emergency and pressure protection valves Anti-false charge, push-pull (hostling) and check valve
- ELECTRICAL LAMPS
- Two 4″ 12-volt incandescent stop tail lamps Rubber grommet mounted on rear frame
- Tires
- Four (4) 295/75R 22.5 low profile steel radial Load range G
- Wheels
- 22.5″ x 8.25" steel disc wheels 10 stud hub pilot mount Pre painted white enamel
- Mud Flaps
- Black plastic flaps with Silver Eagle logo mounted on removable hangers
- Support Leg
- Steel stiff leg with replaceable rubber footpad
- Custom Colors
- We can match your fleets’ color specifications. Also available in galvanized.
- Custom Drawbar Lengths
- We can match your needs from 72″ to 102″
- Polyurethane Bushings
- for longer life
- POLYURETHANE Spring Boots
- for longer life
- 4 Light Braking System
- For safety and turn signals.
